AVR-X7200WA, Black, dynamic

AVR-X7200WA, Black, dynamic

AVR-X7200WA

9.2 Ch. 150W 4K AV Receiver with Wi-Fi & Bluetooth

The Denon AVR-X7200WA is a premium AV receiver with 9.2 channels, Denon's advanced DDSC-HD circuitry, and support for Dolby Atmos and DTS:X.

Color

Black

Black

Select Quality

AVR-X7200WA

Details & Specifications

Multichannel Surround

DTS HD Master / DTS:X Yes / (upgrade)
DTS Neo:X / DTS Neural:X No / Yes (11ch) (update)
Dolby TrueHD / Dolby Atmos Yes / Yes
Dolby ProLogic Ilz / Dolby Surround No / Yes
Auro 3D Yes (upgrade)
Audyssey DSX Yes
Multichannel Stereo Yes
Max Number of Processing (Preamp) Channels 11.2

Sound Enhancements

Mono Block Power Amp Construction Yes (L/R separated)
Discrete Power Amplifier Yes
D.D.S.C. HD Digital Yes (32 bit)
Pure Direct Yes
Gold Plated RCA Terminals Yes
Clock Jitter Reducer Yes
Alpha Processing AL32 Processing Multichannel
Denon Link HD Yes
Audyssey MultEQ XT32 (PRO)
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC Yes
Compressed Audio Restorer Yes

Network

DLNA Certified Yes (v1.5)
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming Yes
Gapless playback Yes (FLAC, WAV)
Photo Streaming (JPEG) Yes
Windows PlayTo / Windows8 Certified Yes / Yes
Internet Radio Yes
Compatible with Remote APP for Smart Phones Android / iOS
Compatible with Remote APP for Tablets Android / iOS
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes

HDMI

HDMI Inputs: Back / Front 7 / 1
HDCP 2.2 support Yes
HDMI Outputs: Main / Zone 2 / 1
Video Conversion Analog -> HDMI Yes
Analog to HDMI Scaling up to 4K 60/50
HDMI to HDMI Scaling up to 4K 60/50
GUI Overlay on HDMI Yes
3D Signal Pass-through Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / Yes / Yes
HDMI Pass-Through in Standby Mode Yes
Picture Adjust / Noise Reduction Yes / Yes
CEC Yes
DSD Audio Capability Yes
Audio Return Channel Yes
Auto LipSync Yes

Multi-room CI

Multi-Room Zones 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout Yes / Yes
Zone HDMI Output from HDMI Source Yes
IP Control / RS232 Control / Web Control / App Control Yes / Yes / Yes / Yes
Remote In / Out Yes / Yes
DC Trigger Output 2

Others

Auto Speaker Setup by Microphone Audyssey MultEQ XT32 + PRO
FL Display 2 lines
Graphic User Interface - GUI Advanced
ISF Certification Yes
GUI Languages 3
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync Yes
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs Outputs

Composite In / Out 4+1 / 2
Component In / Out 3 / 1
HDMI In / Out 7+1 / 3
Multi-room Video Out: Video / HDMI Yes / Yes
Analog In/out 6+1 / No
Phono (MM) In Yes
Digital In: Optical / Coaxial 2 / 2
Multi-room Out: Analog / Digital 2 / No
Multichannel Pre-out Yes (13.2) / No
Subwoofer Out 2 (independent)
7.1 Multichannel Input Yes
Speaker Terminal: Gold Plated Screw / Regular Screw Yes / No
Number of Speaker Terminals 11
Speaker A / B assignable
Bi-amp Drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB Yes / Yes / No / Yes / Yes
USB Audio / Made for iPod / Made for iPhone Yes / Yes / Yes
AM/FM Tuner HD Radio

Specifications

Number of Power Amps 9
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive) No
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) 150 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 190 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 260 W

General

Metal Front Panel Yes
System Remote Control RC-1194
Pre-programmed / Learnable / LCD Display Yes / Yes / Yes
Power Consumption in W 780
Power Consumption No-Sound (ECO On / Off) in W 70 W / 125 W
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Control On Consumption in W 4.5
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches 17.1 x 17.2 x 7.7
17.1 x 17.2 x 10.2
17.1 x 16.9 x 7.7
Weight in LBS 37.7
