Archived

AVR-X3500H

Name: AVR-X3500H
Brand: Denon
SKU: AVRX3500H
Availability: OutOfStock

7.2 Ch. 105W 4K AV Receiver with HEOS® Built-in

The AVR-X3500H 7.2 channel AV Surround Receiver offers the ultimate home theatre experience with Dolby Atmos and DTS:X, plus unparalleled music playback options, thanks to built-in HEOS technology and Amazon Alexa voice compatibility for seamless control.

AVR-X3500H

Details & Specifications

Online Manual

Multichannel Surround

DTS HD Master / DTS:X Yes / Yes
DTS Neo:X / DTS Neural:X No / Yes
Dolby TrueHD / Dolby Atmos Yes / Yes
Dolby ProLogic Ilz / Dolby Surround No / Yes
Auro 3D No
Audyssey DSX No
Multichannel Stereo Yes
Max Number of Processing (Preamp) Channels 7.2

Sound Enhancements

Mono Block Power Amp Construction No
Discrete Power Amplifier Yes
D.D.S.C. HD Digital No
Pure Direct Yes
Gold Plated RCA Terminals No
Clock Jitter Reducer No
Alpha Processing No
Denon Link HD No
Audyssey MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume Yes / Yes
Audyssey LFC Yes
Compressed Audio Restorer Yes

Network

DLNA Certified No
Lossy Formats: MP3 / WMA / AAC Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV Yes / Yes / Yes
DSD Audio Streaming Yes (2.8/5.6MHz)
Gapless playback Yes (FLAC, WAV ,ALAC, DSD)
Photo Streaming (JPEG) No
Windows PlayTo / Windows8 Certified No
Internet Radio Yes (TuneIn)
Compatible with Remote APP for Smart Phones Denon 2016 AVR Remote
Compatible with Remote APP for Tablets Android / iOS / Amazon Kindle
Ethernet Ports Yes
Wi-Fi Yes
Bluetooth Yes
Media Server Yes
HEOS Wireless Multi-Room Technology Yes
FLAC HD 192/24 Yes
WAV 192/24 Yes
ALAC 192/24 Yes
Spotify* Yes (connect)
Pandora Yes
SiriusXM Yes
Other Streaming Services * Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
HEOS App Control Yes
AirPlay / Airplay2 Audio Streaming Yes / Yes

HDMI

HDMI Inputs: Back / Front 7 / 1
HDCP 2.2 support Yes
HDMI Outputs: Main / Zone 2 / 1
Video Conversion Analog -> HDMI Yes
Analog to HDMI Scaling up to 4K 60/50
HDMI to HDMI Scaling up to 4K 60/50
GUI Overlay on HDMI Yes
3D Signal Pass-through Yes
4K Signal Pass-through / Scaling / GUI Overlay Yes / Yes / Yes
HDMI Pass-Through in Standby Mode Yes
Picture Adjust / Noise Reduction Yes / Yes
CEC Yes
DSD Audio Capability Yes
Audio Return Channel Yes
Auto LipSync Yes
HDMI: 3D / 4K / CEC / ARC / InstaPrevue Yes / Yes / Yes / Yes / No
Enhanced Audio Return Channel Yes
HDR / HLG / Dolby Vision Yes (HDR10) Yes / Yes

Multi-room CI

Multi-Room Zones 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog Yes (2ch) Yes (2ch) Yes / Yes
Zone Audio Output: Speaker / Preout Yes / Yes
Zone HDMI Output from HDMI Source Yes
IP Control / RS232 Control / Web Control / App Control Yes / Yes / No / Yes
Remote In / Out Yes / Yes
DC Trigger Output 1
HDMI Diagnostics Yes

Others

Auto Speaker Setup by Microphone Audyssey MultEQ XT32
FL Display 1 line
Graphic User Interface - GUI Advanced
ISF Certification Yes
GUI Languages 3
Setup Assistant Yes
Quick Select Plus / Quick Select Yes / No
Firmware Update by: Network / USB Yes / Yes
Variable Cross Over Yes
Optimized Bass Redirection Yes
Bass Sync No
ECO Mode Yes
Auto Power Off Yes
Sleep Timer Yes

Inputs Outputs

Composite In / Out 3 / 0
Component In / Out 2 / 1
HDMI In / Out 7+1 / 3
Multi-room Video Out: Video / HDMI No / Yes
Analog In/out 5 / 0
Phono (MM) In No
Digital In: Optical / Coaxial 2 / 2
Multi-room Out: Analog / Digital 1 / No
Multichannel Pre-out Yes (7.2)
Subwoofer Out 2
7.1 Multichannel Input No
Speaker Terminal: Gold Plated Screw / Regular Screw No / Yes
Number of Speaker Terminals 7
Speaker A / B assignable
Bi-amp Drive assignable
Multi-Room Speaker Terminal assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB No / No / No / Yes / Yes
USB Audio / Made for iPod / Made for iPhone Yes / No / No
AM/FM Tuner Yes

Specifications

Number of Power Amps 7
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive) 105W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) 135W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive) 215 W

General

Metal Front Panel No
System Remote Control RC-1218
Pre-programmed / Learnable / LCD Display No / No / No
Power Consumption in W 600
Standby Consumption in W 0.1
CEC Standby Consumption in W 0.5
Network Control On Consumption in W No
Maximum Dimensions
Antenna: Horizontal: (W x D x H) in Inches
Antenna: Vertical: (W x D x H) in Inches
W/O Antenna: (W x D x H) in Inches 17.1 x 15.4 x 6.6
( 17.1 x 15.3 x 9.3 )
Weight in LBS 23.8 lbs
